Technical parameters:
| model | unit | XK7120 |
| Spindle hole taper | R8 | |
| X-axis travel | mm | 300 |
| Y-axis travel | mm | 220 |
| Z-axis travel | mm | 300 |
| Distance from spindle to workbench | mm | 45--345 |
| Spindle Center to Column Guide | mm | 255 |
| Workable area | mm | 600x200 |
| Maximum load capacity | Kilogram | 180 |
| Number/width/pitch of T-Slots | 4/12/45 | |
| Maximum spindle speed | r/min | 6000 |
| Spindle speed range | r/min | 400--6000 |
| Spindle motor power | KW | 1.1 |
| Positioning accuracy | mm | 0.04 |
| Repeat positioning accuracy | mm | 0.02 |
| Net weight of the machine tool | Kilogram | 585 |
| Overall size of the machine tool | mm | 1000*950*1850 |
