| Workbench size | mm | 1200*280 |
| T-slot | mm | 5/14/50 |
Vertical stroke
| mm | 650 |
Horizontal itinerary
| mm | 300 |
Vertical stroke
| mm | 430
|
| End mill diameter | mm | 25
|
|
| Face milling capability | mm | 100 |
| Drill diameter | mm | 50 |
Longitudinal feed range
| mm | 15.1-266.4mm/min 6 steps
|
| Horizontal feed range |
| 15.1-266.4mm/min 6 steps |
| End milling spindle stroke |
| 120 |
| Distance from spindle to workbench |
| 80-460 |
Telescopic arm movement stroke
|
| 360 |
End milling spindle taper
|
| MT4 /R8 |
| Horizontal milling spindle taper |
| MT4 |
End milling spindle speed range
|
| 253-4000rpm 8 steps |
| Horizontal milling spindle speed range |
| 32-1320rpm 12 steps |
| End milling spindle motor power | kw | 1.5/0.85 |
| Main motor |
| 2.0/2.4 |
| Packaging size (length*width*height) | mm | 1500*1700*2200 |
weight
| kg | 1200/1300 |
