Technical parameters:
model | unit | C6140×750/1000/1500/2000/3000/4000 | ||
The maximum rotation diameter of the workpiece on the bed | mm | 400 | ||
Maximum workpiece rotation diameter on the tool holder | mm | 210 | ||
Maximum workpiece diameter of saddle groove | mm | 630 | ||
Effective length of saddle groove | mm | 210 | ||
Bed width | mm | 400 | ||
Maximum workpiece length | mm | 750/1000/1500/2000/3000/4000 | ||
Cutter cross section | mm | 25 X25 | ||
Spindle front end tapered hole: | Mo's | No. 6 | ||
Feed quantity | 64 kinds | |||
Spindle speed range (series) | r/min | 10-1400/16-1400 (level 24) | ||
Spindle through hole diameter | mm | 52., 80, 105 | ||
Metric thread range (number of types) | mm | 1-192mm (44 types) | ||
English thread range (number of types) | Teeth/time | 2-24tpi (21 types) | ||
Module-digital thread | 0.25-48 (39 types of modulus) | |||
Diameter thread | 1-96DP (37 types) | |||
Maximum stroke of tailstock spindle | mm | 150mm | ||
Tail seat spindle hole taper | Mo's | Mohs 5 | ||
Tail seat spindle diameter | mm | 75 | ||
Main motor power | kw | 7.5 | ||
Machine tool weight | kg | Gross weight | net weight | |
Length 750mm | 2100 | 1990 | ||
Length 1000mm | 2190 | 2070 | ||
Length 1500mm | 2350 | 2220 | ||
Length 2000mm | 2720 | 2570 | ||
Length 3000mm | 3300 | 3200 | ||
Length 4000mm | 3500 | 3400 | ||
Packaging size | Length 750mm | mm | 2550×1140×1750 | |
Length 1000mm | 2700×1140×1750 | |||
Length 1500mm | 3200×1140×1750 | |||
Length 2000mm | 3700×1140×1750 | |||
Length 3000mm | 4850×1140×1750 | |||
Length 4000mm | 5800×1140×1750 | |||
