Technical parameters:
| model | CA6166B CA6166C | CA6266B CA6266C | |
| Maximum workpiece diameter of the bed | 660mm | ||
| Maximum workpiece diameter on the tool holder | 400mm | ||
| Maximum workpiece diameter of saddle groove | -- | 880mm | |
| Effective length of saddle groove | -- | 210mm | |
| Maximum workpiece length | 750/1000/1500/2000/2200/3000/4000mm | ||
| Bed width | 400mm | ||
| Cutter cross section | 25*25mm | ||
| Spindle | Spindle speed range | 10-1400rpm/16-1400rpm (24-level steps) | |
| Spindle inner hole | 52mm 80mm 105mm | ||
| Spindle hole taper | Motex NO.6 (MT6) Φ90 1:20 Φ113 1:20 | ||
| Feed | Feed quantity | 64 kinds of kind (for each) | |
| Metric threads | (1-192mm) 44 kinds of kinds | ||
| Imperial thread | (2-24tpi)21 kinds of kinds | ||
| Module-digital thread | 0.25-48 (39 types of modulus) (Moduie 39 kinds) | ||
| Diameter thread | (1-96DP) 37 kinds of kinds | ||
| Tail seat | Maximum stroke of tailstock spindle | 150mm | |
| Tailstock | Tail seat spindle diameter | 75mm | |
| Tail seat spindle hole taper | Mohs NO.5 (MT5) | ||
| Main motor | 7.5kW (10HP) | ||
| Packaging size | Overall dimensions for750mm | 2550*1140*1750 | |
| (L*W*H mm) | Overall dimensions for1000mm | 2700*1140*1750 | |
| Overall dimensions for1500mm | 3200*1140*1750 | ||
| Overall dimensions for2000mm | 3700*1140*1750 | ||
| Overall dimensions for 2200mm | 4030*1140*1750 | ||
| Overall dimensions for 3000mm | 4850*1140*1750 | ||
| Overall dimensions for 4000mm | 5800*1140*1750 | ||
| weight | Length | Gross weight net weight | |
| (kg) | GW NW | ||
| Weight for 750mm | 2380 2260 | ||
| Weight for 1000mm | 2570 2450 | ||
| Weight for 1500mm | 2810 2640 | ||
| Weight for 2000mm | 3050 2880 | ||
| Weight for 2200mm | 3390 3180 | ||
| Weight for 3000mm | 3930 3687 | ||
| Weight for 4000mm | 4580 4200 | ||
