Technical parameters:
| model | unit | M7132 | |
| Work surface size of the workbench (length x width x height) | mm | 320x1000/1250/1600 | |
| Maximum working longitudinal motion | mm | 1000/1250/1600 | |
| Maximum distance from the center of the spindle to the working surface | mm | 570 | |
| Maximum lateral movement of the grinding head | mm | 350 | |
| Handshake scale value of vertical feed of grinding head | Each grid | mm | 0.01 |
| revolution | mm | 1 | |
| Quickly lift the motor | strength | KW | 0.37 |
| speed | r/min | 1440 | |
| Grinding wheel size (outer diameter x width x inner diameter) | mm | φ350x40x127 | |
| Grinding wheel speed | r/min | 1440 | |
| Total motor power | KW | 9 | |
| Grinding wheel spindle motor | KW | 5.5 | |
| Oil pump motor | KW | 3 | |
| Parallelism between processing surface and foundation surface | mm | 0.015/1000 | |
| Surface roughness | 嗯 | RA: 0.63 | |
| Net weight/gross weight of the machine tool | Kilogram | 3680/4000/4200 | |
| Packaging size (length x width x height) | mm | 2800/3100/3400×1750×2350 | |
