| model | unit | VMC1050 |
| Workbench size | mm | 1000*550 |
| X-axis stroke | mm | 1000 |
| Y-axis stroke | mm | 550 |
| Z-axis stroke | mm | 550 |
| Large load bearing of workbench | kg | 500 |
| T-shaped groove (quantity - width × clearance) | - | 5-18*90 |
| Spindle speed | rpm | 8000 |
| Spindle taper | mm | BT40 |
| Main motor power | kw | 7.5 |
| Fast movement speed of X/Y/Z axis | m/min | 24/24/20 |
| Cutting feed speed | mm/min | 1-8000 |
| Guide rail form | - | Linear rail |
| Distance from the center of the spindle to the column surface | mm | 525 |
| Distance between the end of the spindle to the surface of the workbench | mm | 130-680 |
| Positioning accuracy | mm | ±0.0075 |
| Repeat positioning accuracy | mm | ±0.005 |
| Tool library | - | Disc Arm 24 |
| Large diameter tool | mm | 78/120 |
| High weight of tool | kg | 8 |
| Machine tool weight | kg | 5200 |
| External dimensions (length x width x height) | mm | 3200*2400*2800 |
