| Main technical parameters | Unit | XK7124 |
| Workbench area | mm | 1000*240 |
| Maximum load of workbench | kg | 200 |
| X Y Z axis travel | mm | 500*240*400 |
| Distance from spindle nose to workbench | mm | 100-500 |
| Distance from spindle center to column guide surface | mm | 300 |
| Spindle hole taper |
| 7:24 30 |
| Spindle speed range | r.p.m | 100-4000 |
| Main motor power | r.p.m | 2200 |
| Workbench fast moving speed | m/min | 4*4*3 |
| Cutting feed speed | mm | 1-4000 |
| X Y Z three-axis lead screw diameter and pitch | mm | 2505 |
| X Y Z three-axis servo motor torque | NM | 6*6*6NM Standard |
| Machine positioning accuracy | mm | 0.01/300 |
| Repeat positioning accuracy | mm | ±0.015 |
| Spindle motor | KW | 2.2 |
| Net weight of machine tool | kg | 1100 |
| Machine tool dimensions | mm | 1520*1560*1800 |
