Technical parameters:
| project | unit | TD65-500 | |
| Spindle machining length (standard) | mm | 160-550 | |
| Single spindle chuck processing length (optional) | mm | 90-260 | |
| Main spindle collet diameter range | mm | φ20-72 | |
| Maximum speed | r/min | 1800 | |
| Main motor | AIN motor power | KW | 7.5 |
| Two axes | x1 x2/z1, 22 axis fast movement speed | m/min | 20/20 |
| x1-x2 axis travel | mm | 430 | |
| Z1-Z2 axis travel | mm | 240 | |
turret | Knife field | mm | 25-25 |
| Boring diameter | mm | φ32 | |
| Net weight of the machine tool | T | 4 | |
| Overall dimension | mm | 2860-1820-1780 | |
